Shining3D - Transcan C Professional 3D Scanner

Product SKU: 6970163084336

Available Stock:
Loading...

A Professional 3D Scanner for Diverse Industries

SHINING3D developed the Transcan C as a professional-grade 3D scanner capturing exceptionally high resolution and accurate scans of objects from small to medium size for a great variety of industries. In addition, the 12 MP cameras help to produce a rich and detailed colour texture for your 3D model, giving an intuitionistic image of the physical object. The Transcan C also features an adjustable scanning range, in order to meet the various object scanning needs of end users. You can smoothly shift between 3 levels of resolution in one project in order to maximize the details and efficiency of your project.

Please Note: The Transcan C requires a Computer with a NVIDIA Graphics Card for use.
Technical Specs
  • Scan Mode: Structured-light scan with automatic turntable
  • Scan Range: 150 mm x 96 mm 丨300 mm x 190 mm
  • Single Shot Accuracy: 0.035 mm丨0.05 mm
  • Scan Speed: <70 s (8 scans/turn without texture)
    <3 s (single frame without texture)
  • Texture Colour: RGB 24-bit color
  • Align Mode: 12 mega pixels, high fidelity color
  • Working Distance: 260 mm 丨480 mm
  • Point Distance: 0.0375 mm;0.075 mm;0.114 mm 0.075 mm;0.154 mm;0.23 mm
  • Data Format: OBJ, STL, ASC, PLY, 3MF
  • Working Temperature: Indoor, room temperature
  • System: Win10; 64-bit
  • Recommended Computer Configuration: Graphics card: NVIDIA GTX/RTX series cards, higher or equal to GeForce RTX 1060; Video memory: ≥4 G; Processor: I7-8700; Memory: 32 GB
  • Size: Host module: 332 mm x 110 mm x 142 mm (bare machine size) Tripod components: 475 mm x 120 mm x 120 mm (bare machine size) Turntable module: 320 mm x 320 mm x 68 mm (bare machine size)
  • Weight: Host module: 2.74 KG (net weight) Tripod assembly: 2.165 KG (net weight) Turntable module: 2.008 KG (net weight)
  • Maximum Turntable Load-Bearing Capacity: ≤10 KG
What's Included
  • Transcan C 3D Scanner
  • ExScan Software
  • Power Cable (x2)
  • Power Adapter (x2)
  • Connection Cable
  • Calibration Board
  • Calibration Board Bracket
  • Calibration Pad
  • Marker
  • Turntable
  • Turntable Connection Cable
  • USB Drive
  • Tripod
  • 1 Year Warranty
  • (OPTIONAL) Geomagic Essentials
    - For Reverse Engineering
Scanned Images
Highlights

An Innovative 3D Scanner

The Transcan C is a multi-functional machine which is able to obtain 3D data quicker and more effectively than previous models. It is also able to scan a variety of objects ranging from small to large sized objects.

A Seamless Scanning Experience
  • The scanning process is fully automatic with the turntable. Combined with the scanning software's stitching algorithm, this ensures the efficient acquisition of 3D data without manual intervention. The software interface is designed to guide you through the simple operation process while providing powerful tools for the hassle-free optimization of your scan results.
Highly Accurate Scanning Solution
  • This compact scanner is able to capture objects with high accuracy (0.035 mm at its inner position, and of 0.05 mm at its outer position). This results in accurate measurements, which are highly valuable across a wide range of applications.



Showing the Transcan C in use

A scan displayed within the software interface with accurate measurements

Accessible High Resolution 3D Modeling

The Transcan C is a straight-forward 3D scanning experience for technical & non-technical users, making it perfect for adding to your workflow!

Multi-Funtioning High Resolution Results
  • The Multi-Resolution Fusion Algorithm allows for a mixture of up to 3 levels of resolution within a single project, to help tackle your most complex scanning projects. This results in high efficiency without any extra work.
Authentic 3D Colour Data Capture
  • Two 12 MP colour cameras are installed to capture a detailed 24-bit color map, replicating the authentic color of the physical object. The Transcan C is the ideal solution to capture 3D colour data for virtual display.

A Fast, Accurate, & Reliable digital solution

The Transcan C is capable of delivering accurate data quickly and effectively. This machine is perfect to use for reverse engineering, archiving, or heritage preservation. Paired with Geomagic Essentials, the Transcan C becomes nearly unstoppable.

Flexible Scanning Range
  • The slide-rail design allows you to easily switch between a scanning range of  150 mm x 96 mm and a larger range of 300 mm x 190 mm in a matter of seconds. This makes scanning objects of varying sizes a breeze.
Quick Reproduction of Fine Surface Details
  • The minimum point distance that the Transcan C can reach is 0.0375 mm (resolution). To properly reproduce fine surface details on an object, you can adjust the Transcan C into its inner position of 150 mm x 96 mm.


Scanned Shoe results
Overview
Highly Efficient Addition to your Workflow

The Transcan C is capable of completing scans in as little as <3 seconds (single frame, no texture) or <70 s (8 scans/turn without texture). This makes the Transcan C ideal for use in projects involving reverse engineering, CAD/CAM, and 3D printing etc.


Hybrid Blue Laser & LED Light
Thanks to the Hybrid structured light source technology, the Transcan C is able to integrate LED structured light and invisible infrared light into one device and adds advanced smart presets in different scan modes. This allows for 3D scanning in a broad range of applications and promotes the popularization of portable 3D scanning technology.

Scan Faster than Ever Before
The latest development in data capture hardware and optimized algorithms make the next-generation Transcan C series a dramatic breakthrough in scanning speed and processing.



Portable & User-friendly Design
With a lightweight and compact size, you can easily take the Transcan C anywhere, just like your laptop! Enjoy plug-and-play installation and a limitless scanning experience.


FAQ
How can I scan dark, reflective objects?

The best way to get an accurate scan for an item which is dark and/or reflective is to spray your object with a matte spray like Aesub. This allows the scanner to accurately pick up all the details of your object.

How does this compare to Photogrammetry?

Photogrammetry (while able to produce decent results with just software and any camera available) still has a few flaws. There are many variables which can affect the accuracy of your scan including camera lens distortion, settings, lighting and shadows. With the Transcan C, everything is self contained within the unit. It projects it's own light and allows for the use of different mode settings to vastly simplify the setup and repeatability of your scans. To learn more, check out the Einscan Pro 2X 2020 Vs. Photogrammetry blog post!

How does Meshing work?

Once you are happy with the point cloud data, you can delete the points you don't need with an intuitive lasso tool right inside the scan program. You are then able to process the point cloud into a water tight mesh. Everything is automated with custom controls, allowing for the production of usable high resolution meshes with ease and predictability. Speak to our Scanning experts to see if the HX is the right scanner for you.

Why Choose EinScan

User Friendly and Highly Detailed

Every scan generates a mesh of high-quality 3D data, allowing you to reconstruct the real geometry of any object with fine details. The Transcan C also utilizes a visible white light when scanning.


Easy Operation, Faster Scanning
One-click scanning makes your life easy, with automatic calibration and no rigid set-up required. The Transcan C is able to process an entire scan in as little as 3-70 seconds.

Compatible with 3D Printers
The Transcan C is able to auto mesh 3D data meaning you get water-tight prints every time! You can also seamlessly connect to a variety of 3D printers once you provide API access for your machine.


One Click Upload for Online File Saving and Data Sharing
This machine allows for support of third-party data sharing platforms in order to access the cloud service. This allows the benefit of one-click uploads for online file archiving or data sharing.

The EinScan H Workflow
