Glass fiber reinforced PPA with exceptional strength, heat resistance, and dimensional stability.
Color
SKU: [S]5.11.19003A01
$272.00 CAD
Sale
Sold out

Price

$272.00 CAD

Stock

Request a Quote | Email This Page

Filament Details

Performance ratings are intended as a general comparison guide. Refer to the Technical Data Sheet (TDS) for detailed specifications and certified values.
Raise3D Industrial PPA GF 1.75mm Filament (1KG) is a high-performance polyphthalamide (PPA) filament reinforced with 15% glass fiber for demanding industrial applications. It offers exceptional rigidity, strength, heat resistance, and dimensional stability while exhibiting lower moisture absorption than conventional nylon materials. With excellent chemical resistance and long-term mechanical performance, PPA GF is ideal for manufacturing durable functional parts used in automotive, aerospace, and industrial environments.
Applications
  • Automobile
  • Aerospace
  • Electrical and electronics (E&E) industry
  • End-use parts

Documentation

Advanced Material

See TDS for information

Adhesion Aid Recommended

Explore Options

Enclosed Chamber Recommended

Helps prevent warping and layer separation

Abrasive Material

A hardened nozzle is Required

Technical Specs

Overview
Net Weight 1kg
Material Compatibility
Material Diameter / Thickness 1.75mm

Notes

This filament is compatible with Raise3D Industrial PPA Support Filament.

Product Highlights

Top Features

A high-temperature composite filament for end-use applications

Raise3D Industrial PPA GF is a glass fiber reinforced composite filament material based on PPA (polyphthalamide or high-performance/high-temperature Nylon). PPA is distinguished from aliphatic polyamides (e.g.PA6) by higher melting point, glass transition temperatures (Tg), lower moisture absorption, and greater dimensional stability. The incorporation of short glass fibers (15wt.%) further improves upon the properties of PPA matrix, which makes PPA GF printed parts promising for end-use applications in automotive, aerospace, electrical and electronics (E&E) industry.

  • High rigidity and strength
  • Excellent thermal performance
  • Lower moisture absorption
  • Dimensional stability
  • Chemical resistance
  • Higher heat distortion temperatures
  • cost-effective

 Benefits

  • High Strength
  • Heat Resistance
  • High Performance-cost Ratio

Recommended Print Settings

  • Nozzle temperature (°C)L: 280-320℃
  • Bed temperature (°C): 65-80℃
  • Layer height (mm): 0.1-0.25 mm
  • Printing speed (mm/s): 30-120 mm/s
  • Cooling fan: OFF
  • Drying temperature (°C): 80-100°C for 4 to 6 hours

Printing Notes:

  • Abrasion of the brass nozzle happens frequently when printing PPA GF. Using an abrasion-resistant nozzle, at minimum a Steel nozzle should be used or preferably, a SiC nozzle.
  • After the printing, it is recommended to anneal the model in the oven at 80-100°C for 4 to 8 hours and cool the room temperature natu
