Form Cure - Post Curing Oven

Product SKU: FH-CU-01

Available Stock:


Reliable, Professional Post-Curing

Form Cure is finely tuned to bring parts to their maximum mechanical properties. Once the time is up, parts are fully cured and ready for peak performance.

Technical Specs
Technical Data Sheet
  • Printer Compatibility: Form 3, Form 2, Form 4
  • Dimensions: 26.2 x 26.2 x 34.0 cm (10.3 x 10.3 x 13.4 in)
  • Height when open: 64 cm (25.2 in)
  • Weight: 5.6 kg (12.4 lbs)
  • Turntable Diameter: 19.3 cm (7.6 in)
  • Maximum Part Size: 14.5 × 14.5 × 17.5 cm (5.7 x 5.7 x 6.9 in)
  • Suggested Operating Environment: 18-28 °C (64-82 °F)
  • Power Requirements: 90–240 V
    6.0 A 50/60 Hz
    144 W
    An advanced heating system precisely controls curing temperatures up to 80 °C
    13 multi-directional LEDs emit the optimal wavelength of light for curing Formlabs materials
    A rotating turntable provides uniform exposure during post-curing
Built to complete the stereolithography (SLA) engine, Form Wash and Form Cure streamline your 3D printing process to produce better results with less time and effort.

Maximum Mechanical Properties with Form Cure

  • Advanced Heating: Precise heat control is the key to successful post-curing. Form Cure’s chamber is able to achieve temperatures of up to 80 C.
  • Balanced UV Light: 13 LEDs use 405 nm Light to trigger the post-curing reaction, working with the heater to post-cure parts.
  • Uniform Exposure: A rotating turntable, heat flow, and dispersed lights provide uniform exposure during post-curing.
  • An Intuitive Interface: It’s easy to set Form Cure’s temperature and post-cure time. For Standard Resins, simply use the default. For all other materials, use recommended settings for optimum performance.
