Formlabs Form 4 Starter Bundle

Product SKU: PKG-F4-WSVC-BASIC

$6,475.00

Available Stock:
Loading...

Now In Stock.
First 20 purchases of the Formlabs Form 4 qualify for a free Formlabs t-shirt! Disclaimer: limited sizing available on a 1st come first served basis. T-shirt is shipped with the printer.

Formlabs Form 4 Starter Bundle - Blazing Speed Meets Industrial Production

Form 4 is a blazing fast masked SLA 3D printer that combines an industry-leading materials library with a reliable, accurate print engine. Turn your ideas into reality faster than ever with easy workflows, leading reliability, and stunning part quality using the Form 4 ecosystem.
Form 4’s speed is driven by Formlabs’ new Low Force Display™ Print Engine, a powerful combination of ultra-high power LEDs, collimating lenses, optical filters, and a robust liquid crystal display. Together they cure each layer of resin rapidly — regardless of part size or quantity. With tight tolerances, parts printed in every resin on Form 4 will match your design parameters, every time.

Features

Get more done with most prints in under 2 hours.

Game Controller Print Time:

Form 4: 1h 38m
Benchmark FDM: 3h 37m
Benchmark SLA: 4h 11m
Form 3+: 10h 47m

Electrical Connector Print Time:

Form 4: 1h 28m
Benchmark FDM: 9h 12m
Benchmark SLA: 2h 16m
Form 3+: 9h 43m

Produce stunning parts that always fit, rivalling injection molded parts.

Sharpest Details
Highly collimated light and 50 µm pixel size with pre-tuned anti-aliasing for subpixel resolution
Smoothest Surfaces
Lower peel forces, light touch supports, and 50 µm pixel size with pre-tuned anti-aliasing
Most Accurate Assemblies
±0.15% XY dimensional tolerances so assembles always fit.

Tackle any problem with our industry-leading materials.

Formlabs has a vast library of specific use case resins as well as general purpose resins that still offer enchanced mechanical properties over other resins. Use Formlabs Resin for:

General Purpose
Tough. Impact-resistant, PP-like, ABS-like
Rigid. Ultra stiff, high strength, glass-filled

Flame Retardant. UL 94 V-0 certified, FST rated
Silicone. 100% pure silicone
Elastic. Translucent elastomers. 50A and 80A shore hardness

Biocompatible. Class I and Class II with Form 4B
Polyurethane. Long-term durability, true polyurethane
Ceramic. 99.99% pure alumina technical ceramic

Unmatched reliability. Stop coming back to failed prints.

With new systems in place to ensure you never come back to a failed print

Validated Print Settings: Formlabs optimization engineers put hundreds of printed parts to the test to ensure each material performs to the most reliable standards, right out of the box.
Intelligent Control Systems: Six control systems precisely measure and maintain the temperature, resin level, print forces, and print status inside your printer.
Long-Lasting Consumables: Robust hardware that was engineered for years of use.
Tank rated for >75,000 layers for all materials.
Light Processing Unit rated for >750,000 layers.

Factory Calibration: 60-point calibration and quality control inspection before your printer even leaves the factory.
Remote Monitoring: Monitor your prints and manage your printers from anywhere with an integrated camera, preventative maintenance reminders, and our free Dashboard software.

A system so intuitive that anyone can learn to print in 15 minutes

1. Import your model and prepare your print

Smart auto-orientation
Advanced support generation
Live printability checks

2. Load a material and click print

Validated print settings
No-hassle cartridge and tank
Automatic resin dispensing

3. Remove, wash, cure

Quick release part removal
Automatic part cleaning
precision post-curing for peak material properties

4. Finish your part

Light touch supports for quick, clean support removal
Optional sanding, coating, or painting

Testimonies

"Form 4 is our go-to choice for projects needing tight tolerances and engineering-grade materials. It produces high-performance parts with amazingly fast print times and makes it possible for our model makers to produce multiple iterations in a 24-hour period.

- Mark Honschke, Additive Prototyping Lead -Microsoft

"The dramatic increase in print speed for Form 4 has significantly accelerated our fabrication cycle - to the point where I can iterate through many different designs every day and go from design to usable functional parts within the hour"

-Matt Mullin, Laser Engineer -NASA

"I really appreciate the reliability paired with the speed. it's not one or the other, like many other tools. Now I can commit to internal deadlines and feel confident that I can deliver every time.

Bruno Alves, Development Engineer AM/IM -Ford

Tech Specs

Technology: Low Force Display (LFD)
Build Volume (W x D x H): 20.0 x 12.5 x 21.0cm | 7.9 x 4.9 x 8.3in
Layer Thickness (Z resolution): 25 - 300 microns
XY Resolution: 50 Microns
Average Print Speed (100 µm layer height): 40mm/h
Maximum Print Speed: 100mm/h

Resin Tank Lifetime: 75,000+ layers with any Formlabs material
Printer weight: 18.3kg | 40.4lb
Printer dimensions: 39.8 x 36.7 x 55.4cm | 15.7 x 14.5 x 21.9in
Warranty and service: One-year warranty included | Paid service and extended warranty options available
Software compatibility: Windows 7 and up | Mac os X 10.12 and up
File Types accepted: STL, OBJ, 3MF

What's Included

1 x Formlabs Form 4 3D Printer
1 x Formlabs Form 4 Resin Tank
1 x Formlabs Form 4 Mixer
1 x Formlabs Form 4 Build Platform
1 x Formlabs Form 4 Finish Kit
