Forward AM | Ultrafuse® ASA Filament - 750gr. (Netherlands)

Forward AM | Ultrafuse® ASA Filament - 750gr. (Netherlands)

UV-resistant ASA filament with excellent durability, weather resistance, and dimensional stability.
$49.50 CAD
Sale
Sold out

Price

$49.50 CAD $49.50

Stock

Request a Quote | Email This Page

Filament Details

Performance ratings are intended as a general comparison guide. Refer to the Technical Data Sheet (TDS) for detailed specifications and certified values.
BASF Forward AM Ultrafuse® ASA 1.75mm Filament (750g) is an engineering-grade filament designed for durable outdoor and functional applications. It provides excellent UV resistance, weatherability, and mechanical performance while maintaining dimensional stability and a high-quality surface finish. Compared to ABS, ASA offers improved resistance to sunlight and environmental exposure, making it ideal for long-lasting parts used in demanding conditions.
Applications
  • Outdoor use
  • Functional prototypes
  • Chemical environment
  • Reasonable heat resistance

UV resistant

See TDS for Details

Resistant to Temperature Cycling.

See TDS for Details

Prone to Shrinking.

See TDS for Details

Intermediate Material

See TDS for information

Adhesion Aid Recommended

Explore Options

Enclosed Chamber Recommended

Helps prevent warping and layer separation

Technical Specs

Overview
Net Weight 750gr
Material Compatibility
Material Diameter / Thickness 2.85mm

Links

Notes

These are industrial-grade materials that require experienced 3D printing knowledge. Please consult the technical data sheet. It is recommended to print with an enclosure.

Warning: Ultrafuse ASA can adhere extremely well to the build plate. Take caution removing the prints as it may take chunks from the build plate. Glue stick recommended.

Product Highlights

Top Features

Ultrafuse ASA is a high-performance thermoplastic with similar mechanical properties as ABS. ASA offers additional benefits such as high outdoor weather resistance. The UV resistance, toughness, and rigidity make it an ideal material to 3D-print outdoor fixtures and appliances without losing its properties or color. When also taking into account the high heat resistance and high chemical resistance, this filament is a good choice for many types of applications.

Benefits at a Glance

  • UV stabilized
  • Weather resistance
  • Long life span
  • Very tough
  • Resistant to wear and tear
  • Chemical resistance

Material Properties

  • Tensile Strength (MPa): 12.0 (ZX), 34.6 (XY)
  • Flexural Modulus (MPa): 1041 (ZX), 1638 (XZ), 1733 (XY)
  • Elongation at Break: 1.0 % (ZX), 4.5 % (XY)
  • Impact Strength Izod notched (kJ/m2): 1.9 (ZX), 11.4 (XZ), 8.7 (XY)
  • Impact Strength Izod unnotched (kJ/m2): 6.8 (ZX), 39.3 (XZ), 36.8 (XY)
  • HDT @ 0.45 MPa: 101 oC

Printing Guidelines*

  • Nozzle Temperature: 260-280 °C
  • Build Chamber Temperature: Closed chamber, passively heated
  • Bed Temperature: 100 - 120 °C
  • Bed Material: Spray, PC adhesive
  • Nozzle Diameter: ≥ 0.4 mm
  • Print Speed: 30 -60 mm / s

*The product data is provided in good faith and represents typical properties based on our current knowledge and experience; these data are not to be construed as specification limits or mini- mum values. Product properties may be changed without notice. This document does not create any liability, warranty or guarantee of product performance. It is the buyer’s responsibility to determine the suitability of Ultrafuse® products for the intended application.
